Product Type:
Ethernet Switch
Interfaces/Ports :
24 x 10Base-T/100Base-TX - RJ-45 - PoE, 2 x 10Base-T/100Base-TX/1000Base-T-RJ-45, 2 x SFP (mini-GBIC)
Connectivity Media:
Category 3 UTP 10Base-T, Category 4 UTP 10Base-T, Category 5 UTP 10/100/1000Base-T
Bandwidth :
16Gbps Switching Fabric, 6.5Mbps Forwarding Rate For 64-byte Packet
I/O Expansions:
Two Total- SFP (mini-GBIC) Shared
Network & Communication:
Layer 2
Management & Protocols:
CLI, Telnet, HTTP, Syslog, DHCP, RMON, IEEE 802.1p QoS, IEEE 802.1Q VLAN, SNMP v1, v2, v2c, v3, Cisco Works LAN Management Solution
Configurable :
Up to 8000 MAC addresses
Authentication Method:
RADIUS, TACACS+, Secure Shell v.2 (SSH2)
IEEE Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
Memory:
64 MB DRAM, 32 MB flash memory
Status Indicators:
Link activity, port transmission speed, port duplex mode, power, link OK, system
Operating System:
LAN Base Image
Software Included:
Cisco LAN Base software
Features:
Redundant Power System (RPS) connector
Input Voltage:
100 V AC to 240 V AC
Power Consumption:
433 Watt
Enclosure Type:
Rack-mountable - 1U
Dimensions H x W x D:
9.0" x 14.0" x 22.0"
Compliant Standards:
CE, TUV GS, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, FCC Part 15, UL 1950 Third Edition, CSA 22.2 No. 950 Third Edition
Temperature :
Min 23 °F/ Max 113 °F Operating
Humidity Range:
10 - 90% Operating
Green Compliance:
Green Compliance Certificate, Authority: RoHS
