Product Type:
Ethernet Switch
Connectivity Media:
Category 3 UTP 10Base-T, Category 4 UTP 10Base-T, Category 5 UTP 10/100/1000Base-T
Bandwidth :
32Gbps Switching Fabric, 4.4Gbps Forwarding Bandwidth, 6.4Mpps Forwarding Rate For 64-byte Packet
Interfaces/Ports :
Twenty-four Managed Ethernet 10/100 ports and Two 10/100/1000 TX uplinks, Fast Ethernet Ports
Network & Communication:
Layer 2
Management:
Cisco Network Assistant, CiscoWorks Support, Device manager, Express Setup, CiscoView application, Network Assistant Software
Protocols:
TFTP, NTP,Cisco IOS CLI, SAA,VLAN trunksfrom any port using 802.1q tagging, Cisco VTP, Cisco Discovery (Versions 1 and 2)
Remote Management Protocol:
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2
Authentication Method:
RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Redundant Power:
Redundant Power System (RPS) connector
Enclosure Type:
Rack-mountable - 1U
Memory:
64 MB DRAM, 32 MB flash memory
Configurable :
Up to 8000 MAC addresses, and Up to 255 IGMP groups
Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
Status Indicators:
Link activity, port transmission speed, port duplex mode, power, link OK, system
Input Voltage:
100 V AC to 240 V AC
Power Consumption:
28 Watt
Compliant Standards:
CE, FCC Class A certified, TUV GS, cUL, NOM, VCCI Class A ITE, IEC 60950, EN55024, EN55022 Class A, CSA 22.2 No. 60950, FCC Part 15, MIC, UL 1950 Third Edition, UL 60950-1, EN 60950-1
Temperature :
Min 23 °F/ Max 113 °F Operating
Software Included:
Cisco LAN Base software
Dimensions H x W x D:
9.0" x 14.0" x 22.0"
