Product Type:
Security Router
Connectivity Media:
Category 5 UTP
WAN/LAN Ports:
Gigabit Ethernet (10/100/1000) WAN port/ 4-port, full-duplex 10/100/1000 Ethernet switch
Routing:
Static routing, RIPv1 and RIPv2, Inter-VLAN routing
Layer 2:
Port-based and 802.1Q tag-based VLANs, RSTP for loop detection and faster reconfiguration, 4 active VLANs (4094 range)
Network:
DHCP Server, DHCP Client, DHCP Relay Agent, DHCP Server supports static IP address based on MAC address, DNS Relay, Dynamic DNS, DynDNS, TZO, NAT, PAT, NAPT,SIP, ALG support, and NAT traversal
IPv6:
Dual-stack IPv4 and IPv6, 6 to 4, Stateless address auto-configuration, DHCP v6, IMCP v6
Security Access Control:
MAC-based, IP-based access control list (ACL)
Security Firewall:
SPI firewall
Security Content Filtering:
Static URL blocking or keyword blocking, Dynamic filtering through Trend Micro Protect Link Gateway Security Service (optional)
Intrusion Prevention System :
IP sweep detection, Application anomaly detection HTTP, FTP, Telnet, RCP, Peer-to-peer control, Instant messenger control, Layer 3/Layer 4 protocol IP, TCP, UDP, ICMP normalization
Secure Management:
HTTPS, Username/password
Security 802.1X:
Port-based RADIUS authentication switching EAP-MDS, PEAP
VPN:
5 VPN tunnels for remote client access, 5 IPsec gateway-to-gateway tunnels for branch office connectivity, Triple 3DES encryption, MD5, SHA1 authentication, IPsec NAT=T, VPN PPTP, L2TP, IPsec
Management:
SNMP version 1, 2c, Event logging local, syslog, Email alerts, Firmware upgradable through web browser Flash, RAM Diagnostics, Built-in browser-based configuration
Standard Protocol:
IEEE802.3, 802.3u, 802.1x, RFC791 (IP Protocol)
Performance:
NAT throughput: 800 Mbps when IPS is disabled
Dimensions W x D x H:
6.69" x 1.61". x 6.69"
Compliance:
IEEE 802.3/802.3u, IEEE 802.1X (security authorization), RFC 791 (IPv4), RFC 2460 (IPv6), RFC 1058 (RIPv1), RFC 1723 (RIPv2)
Temperature :
0º to 40ºC (32º to 104º F) Operating
Humidity:
10 to 85% relative humidity (noncondensing
